◆窓板・石英 角形 (Fused Silica. Rectangular Windows Polished)
|
標準光学研磨 ( Standard Polishing grade ) |
寸法公差 ±0.1mm (Tolerance ±0.1mm) |
|
材質 無印 :UV-grade(合成石英) (material) (no remarks) OX : OX-grade(溶融石英) I R : I R-grade |
※上記に関する特記事項、特殊形状などは、備考欄をご参照ください。
※その他、特注品にも対応いたしますので、是非ご相談ください。お問い合わせはこちら
※*の表記は本年度の追加商品です。
※こちらに記載されたサイズ以外も対応可能です。
| 品番 | 外形 × 板厚 | 価格 (税込) | 備考 |
| FQ1.5SQ-100 | 1.5 × 1.5 × 100.0 mm | ¥38,500 | 100×1.5 4面研磨 |
| FQ5.5SQ-1 | 5.5 × 5.5 × 1.0 mm | ¥3,300 | |
| FQ9.5SQ-0.7 | 9.5× 9.5 × 0.7 mm | ¥5,500 | |
| FQ10-3-0.3OX | 10.0× 3.0 × 0.3 mm | ¥5,500 | OX |
| FQ10-3-0.5OX | 10.0× 3.0 × 0.5 mm | ¥5,500 | OX |
| FQ10-5-0.3無蛍光 | 10.0 × 5.0 × 0.3 mm | ¥15,400 | 無蛍光 |
| FQ10-5-2.0無蛍光 | 10.0 × 5.0 × 2.0 mm | ¥13,200 | 無蛍光 |
| FQ10-5-3 | 10.0 × 5 × 3.0 mm | ¥6,600 | |
| FQ10SQ-0.1 | 10.0 × 10.0 × 0.1 mm | ¥7,700 | |
| FQ10SQ-0.15 | 10.0 × 10.0 × 0.15 mm | ¥7,700 | |
| FQIR10SQ-0.17 | 10.0 × 10.0 × 0.17 mm | ¥16,500 | IR |
| FQIR10SQ-0.2 | 10.0 × 10.0 × 0.2 mm | ¥16,500 | IR |
| FQ10SQ-0.2 | 10.0 × 10.0 × 0.2 mm | ¥7,700 | |
| FQ10SQ-0.25 | 10.0 × 10.0 × 0.25 mm | ¥7,700 | |
| FQ10SQ-0.3無蛍光 | 10.0 × 10.0 × 0.3 mm | ¥17,600 | 無蛍光 |
| FQ10SQ-0.3OX | 10.0 × 10.0 × 0.3 mm | ¥7,150 | OX |
| FQ10SQ-0.5OX | 10.0 × 10.0 × 0.5 mm | ¥5,500 | OX |
| FQ10SQ-0.2 | 10.0 × 10.0 × 0.2 mm | ¥7,700 | |
| FQ10SQ-0.5 | 10.0 × 10.0 × 0.5 mm | ¥4,400 | |
| FQ10SQ-0.7 | 10.0 × 10.0 × 0.7 mm | ¥4,400 | |
| FQ10SQ-1 | 10.0 × 10.0 × 1.0 mm | ¥4,400 | |
| FQIR10SQ-1 | 10.0 × 10.0 × 1.0 mm | ¥13,200 | IR |
| FQ10SQ-2 | 10.0 × 10.0 × 2.0 mm | ¥4,400 | |
| FQ10.5SQ-1 | 10.5 ×10.5 × 1.0 mm | ¥4,400 | |
| FQ11SQ-1.5 | 11.0 ×11.0 × 1.5 mm | ¥4,400 | |
| FQ15-10-1 | 15.0 ×10.0 × 1.0 mm | ¥4,400 | |
| FQ15-SQ0.5 | 15.0 ×15.0 × 0.5 mm | ¥4,400 | |
| FQ15SQ-1 | 15.0 ×15.0 × 1.0 mm | ¥4,400 | |
| FQIR15SQ-3 | 15.0 ×15.0 × 3.0 mm | ¥17,600 | IR |
| FQ16-5.9-1 | 16.0 ×5.9 × 1.0 mm | ¥4,400 | |
| FQ16-10-1 | 16.0 ×10.0 × 1.0 mm | ¥5,500 | |
| FQ18.8SQ-0.5 | 18.8 ×18.8 × 0.5 mm | ¥5,500 | |
| FQ20-6-1 | 20.0 × 6.0 × 1.0 mm | ¥4,400 | |
| FQ20SQ-0.1 | 20.0 × 20.0 × 0.1 mm | ¥7,700 | |
| FQ20SQ0.25 | 20.0 × 20.0 × 0.25 mm | ¥7,700 | |
| FQ20SQ-0.25AR | 20.0 × 20.0 × 0.25 mm | ¥16,500 | ARコート付 |
| FQIR20SQ-0.5 | 20.0 × 20.0 × 0.5 mm | ¥8,800 | IR |
| FQ20SQ-0.7 | 20.0 × 20.0 × 0.5 mm | ¥5,500 | |
| FQ20SQ-1 | 20.0 × 20.0 × 1.0 mm | ¥4,400 | |
| FQ20SQ-1無蛍光 | 20.0 × 20.0 × 1.0 mm | ¥19,800 | 無蛍光ESL-1 |
| FQ20SQ-2 | 20.0 × 20.0 × 2.0 mm | ¥4,400 | |
| FQ20SQ-2SP | 20.0 × 20.0 × 2.0 mm | ¥8,800 | 全面研磨 |
| FQ20SQ-5 | 20.0 × 20.0 × 5.0 mm | ¥8,800 | |
| FQ23SQ-0.6 | 23.0 × 23.0 × 0.6 mm | ¥5,500 | |
| FQ24-14-1 | 24.0 × 14.0 × 1.0 mm | ¥4,400 | |
| FQ24SQOX | 24.0 × 24.0 × 0.5 mm | ¥5,500 | OX |
| FQ24SQ-0.5 | 24.0 × 24.0 × 0.5 mm | ¥5,500 | |
| FQ25-6-1 | 25.0 × 6.0 × 1.0 mm | ¥4,400 | |
| FQ25-9-1 | 25.0 × 9.0 × 1.0 mm | ¥4,400 | |
| FQ25-10-2 | 25.0 × 10.0 × 2.0 mm | ¥16,500 | |
| FQ25-15-1 | 25.0 × 15.0 × 1.0 mm | ¥5,500 | |
| FQ25SQ-0.5 | 25.0 × 25.0 × 0.5 mm | ¥5,500 | |
| FQ25SQ-1無蛍光 | 25.0 × 25.0 × 1.0 mm | ¥22,000 | 無蛍光ESL-1 |
| FQ25SQ-2 | 25.0 × 25.0 × 2.0 mm | ¥5,500 | |
| FQ25SQ-2coat | 25.0 × 25.0 × 2.0 mm | ¥8,800 | 片面crtAuコート |
| FQIR25SQ-3 | 25.0 × 25.0 × 3.0 mm | ¥27,500 | IR |
| FQ25.4SQ-40 | 25.4 × 25.4 × 40.0 mm | ¥99,000 | 60/40,λ/2 at 633nm ARコート 400nm |
| FQ30-10-1 | 30.0 × 10.0 × 1.0 mm | ¥4,400 | |
| FQ30-14-1 | 30.0 × 14.0 × 1.0 mm | ¥5,500 | |
| FQ30SQ-1 | 30.0 × 30.0 × 1.0 mm | ¥7,150 | |
| FQIR30SQ-1 | 30.0 × 30.0 × 1.0 mm | ¥17,600 | IR |
| FQ32SQOX-0.5 | 32.0 × 32.0 × 0.5 mm | ¥6,600 | OX |
| FQ35SQ-2 | 35.0 × 35.0 × 2.0 mm | ¥22,000 | |
| FQ35SQ-2DR | 35.0 × 35.0 × 2.0 mm | ¥30,800 | 穴付 |
| FQ35SQ-3 | 35.0 × 35.0 × 3.0 mm | ¥22,000 | |
| FQ35SQ-3 | 35.0 × 35.0 × 3.0 mm | ¥30,800 | IR |
| FQ35SQ-3DR | 35.0 × 35.0 × 3.0 mm | ¥30,800 | 穴付 |
| FQ38-13-1 | 38.0 × 13.0 × 1.0 mm | ¥4,400 | |
| FQIR38.5-19.5-4 | 38.5 × 19.5 × 4.0 mm | ¥30,800 | IR |
| FQIR38.5-19.5-4DR | 38.5 × 19.5 × 4.0 mm | ¥38,500 | IR 穴付 |
| FQ40-5-1.5 | 40.0 × 5.0 × 1.5 mm | ¥4,400 | |
| FQ40-10-1 | 40.0 × 10.0 × 1.0 mm | ¥4,400 | |
| FQ40-10-1.5 | 40.0 × 10.0 × 1.5 mm | ¥5,500 | |
| FQ40-19-1無蛍光 | 40.0 × 19.0 × 1.0 mm | ¥24,200 | 無蛍光7980UV ESL-1同等品 |
| FQ40-20-1 | 40.0 ×20.0 × 1.0 mm | ¥8,800 | |
| FQ40-20-15 | 40.0 ×20.0 × 15.0 mm | ¥30,800 | |
| FQ40-28-2 | 40.0 × 28.0 × 2.0 mm | ¥11,000 | |
| FQ40-35-4 | 40.0 × 35.0 × 4.0 mm | ¥16,500 | |
| FQ40-35-4coat | 40.0 × 35.0 × 4.0 mm | ¥30,800 | 片面cr+Auコート |
| FQ41-23-6 | 41.0 × 23.0 × 6.0 mm | ¥33,000 | IR |
| FQ41-23-6DR | 41.0 × 23.0 × 6.0 mm | ¥41,800 | IR |
| FQ45-11-1 | 45.0 × 11.0 × 1.0 mm | ¥8,800 | |
| FQ45-11.5-1 | 45.0 × 11.5 × 1.0 mm | ¥8,800 | |
| FQ45-25-1 | 45.0 × 25.0 × 1.0 mm | ¥11,000 | |
| FQ45-25-1ITO | 45.0 × 25.0 × 1.0 mm | ¥27,500 | 片面ITOコート200Å〜300Å |
| FQ45-30-4coat | 45.0 × 30.0 × 4.0 mm | ¥33,000 | 片面 cr ＋ Auコート |
| FQ49.8SQ-1 | 49.8 × 49.8 × 1.0 mm | ¥30,800 | |
| FQ49.8SQ-0.7 | 49.8 × 49.8 × 0.7 mm | ¥30,800 | |
| FQ50-10-2 | 50.0 × 10.0 × 2.0 mm | ¥11,000 | |
| FQ50-20-1 | 50.0 × 20.0 × 1.0 mm | ¥13,200 | |
| FQ50-20-2 | 50.0 × 20.0 × 2.0 mm | ¥36,300 | |
| FQ50-35-4coat | 50.0 × 35.0 × 4.0 mm | ¥38,500 | 片面cr+Auコート2000Å程度 |
| FQ52-50.8-1 | 52.0 × 50.8 × 1.0 mm | ¥30,800 | |
| FQ58.42SQ-1 | 58.42 × 58.42 × 1.0 mm | ¥27,500 | |
| FQ64.5-63.5-7.8 | 64.5 × 63.5 × 7.8 mm | ¥38,500 | 4-R3 |
| FQ64.5-63.5-8 | 64.5 × 63.5 × 8.0 mm | ¥38,500 | 4-R3 |
| FQ70-50-4 coat | 70.0 × 50.0 × 4.0 mm | ¥44,000 | 片面 cr ＋ Auコート |
| FQ74.7-24.7-1 | 74.7 × 24.7 × 1.0 mm | ¥19,800 | |
| FQ75-25-0.7 | 75.0 × 25.0 × 0.7 mm | ¥19,800 | E78-38 |
| FQ75-26-1 | 75.0 × 26.0 × 1.0 mm | ¥19,800 | |
| FQ76-26-0.5 | 76.0 × 26.0 × 0.5 mm | ¥19,800 | |
| FQ76-26-2 | 76.0 × 26.0 × 2.0 mm | ¥19,800 | |
| FQ80-30-0.5 | 80.0 × 30.0 × 0.5 mm | ¥19,800 | |
| FQ80SQ-2.3 | 80.0 × 80.0 × 2.3 mm | ¥33,000 | |
| FQ85-35-3 | 85.0 × 35.0 × 3.0 mm | ¥27,500 | |
| FQ100-76-1 | 100.0 × 76.0 × 1.0 mm | ¥27,500 | |
| FQ100-76-1ITO | 100.0 × 76.0 × 1.0 mm | ¥33,000 | 片面ITOコート，10Ω-cm |
| FQ100SQ-1 | 100.0 × 100.0 × 1.0 mm | ¥30,800 | |
| FQ150-30-25 | 150.0 × 30.0 × 25.0 mm | ¥60,500 | |
| FQ170-50-2.5 | 170.0 × 50.0 × 2.5 mm | ¥33,000 | 4面研磨 |
| FQ170-55-2.5 | 170.0 × 55.0 × 2.5 mm | ¥33,000 | |
| FQ180-90-5 | 180.0 × 90.0 × 5.0 mm | ¥88,000 | |
| FQ200-15-1 | 200.0 × 15.0 × 1.0 mm | ¥15,400 |
